Excision (TY703) HSS-E (M35) Metric Cold Forming Tap with Oil Grooves (TiAlN Coated)
Pickup available at Head Office
Usually ready in 2-4 days
Care information
Care information
Always use caution and common sense when working with tools.
Delivery and Shipping
Delivery and Shipping
Most in-stock orders are dispatched within 1–2 business days. After dispatch, delivery is estimated at 1–7 business days to most Australian metro and regional areas. Remote destinations and custom or special orders may take longer. Delivery timeframes are estimates. See our Shipping Policy for details.
Excision (TY703) HSS-E (M35) Metric Cold Forming Tap with Oil Groov...
Excision (TY703) HSS-E (M35) Metric Cold Forming Tap with Oil Grooves (TiAlN Coated). Forming taps produce internal threads by displacing material rather than cutting chips.
Choosing the right specification
Use the specified forming-tap drill size and choose the thread form, pitch and material application for the job.
Product details
(TY703) HSS-E (M35) Metric Cold Forming Tap with Oil Grooves (TiAlN Coated) is an HSS-E (M35), TiAlN coating, DIN371 tap range for cutting internal threads. Thread size, pitch, geometry and length remain tied to the selected option.
Product details
- Suitable for threading soft materials with at least 8-10% elongation.
- The pre-drilling holes are bigger than normal sized holes.
- Specified features include HSS-E (M35), TiAlN coating, DIN371.
- Thread and geometry details are grouped for faster application matching.
Choose by Size and Pitch (mm), then confirm work material and hole type against current cutting data.
- Size: M3; Pitch (mm): 0.5 — Part TY703206
- Size: M4; Pitch (mm): 0.7 — Part TY703246
- Size: M5; Pitch (mm): 0.8 — Part TY703286
- Size: M6; Pitch (mm): 1 — Part TY703316
- Size: M8; Pitch (mm): 1.25 — Part TY703366
- Size: M10; Pitch (mm): 1.5 — Part TY703426
- Size: M12; Pitch (mm): 1.75 — Part TY703506
- Size: M16; Pitch (mm): 2 — Part TY703606
- Material / grade: HSS-E
- Thread form: metric
- Model / series reference: TY703
Specifications and options
| Size | M3 M4 M5 M6 M8 M10 M12 M16 |
|---|---|
| Pitch (mm) | 0.5 0.7 0.8 1 1.25 1.5 1.75 2 |
Match each specification to its product code
| Size | Pitch (mm) | Product code (SKU) |
|---|---|---|
| M3 | 0.5 | SETY703206 |
| M4 | 0.7 | SETY703246 |
| M5 | 0.8 | SETY703286 |
| M6 | 1 | SETY703316 |
| M8 | 1.25 | SETY703366 |
| M10 | 1.5 | SETY703426 |
| M12 | 1.75 | SETY703506 |
| M16 | 2 | SETY703606 |
