Excision (ML122) HSS-E (M35) Dovetail Cutters (Flat Shank)
Excision (ML122) HSS-E (M35) Dovetail Cutters (Flat Shank). Dovetail cutters machine an angled dovetail profile.
Choosing the right specification
Match cutting diameter, included angle, face width and shank to the required dovetail and tool holder.
Product details
Product details
Recommanded for use in place of arbor and threaded hole type cutters to reduce set time and facilitate handling.
Specifications
| Flute | Multi Flute |
| Helix Angle | 0° |
| Cutting Edge Shape | Dovetail Cutters |
| Size Min | D16.0 |
| Size Max | D50.0 |
| Surface Treatment | Uncoated |
- Specified features include HSS-E (M35), 6-flute geometry.
Choose by Cutter Diameter (mm) and Width of Face (mm) and No. of Teeth and verify fit against the intended equipment or tooling system.
- Cutter Diameter (mm): 16; Width of Face (mm): 6.3; No. of Teeth: 6 — Part ML12201601
- Cutter Diameter (mm): 20; Width of Face (mm): 8; No. of Teeth: 6 — Part ML12202001
- Cutter Diameter (mm): 22; Width of Face (mm): 9; No. of Teeth: 6 — Part ML12202201
- Cutter Diameter (mm): 25; Width of Face (mm): 10; No. of Teeth: 8 — Part ML12202501
- Cutter Diameter (mm): 28; Width of Face (mm): 11; No. of Teeth: 8 — Part ML12202801
- Cutter Diameter (mm): 32; Width of Face (mm): 12.5; No. of Teeth: 10 — Part ML12203201
- Cutter Diameter (mm): 38; Width of Face (mm): 16; No. of Teeth: 12 — Part ML12203801
- Cutter Diameter (mm): 40; Width of Face (mm): 13; No. of Teeth: 12 — Part ML12204001
- Cutter Diameter (mm): 50; Width of Face (mm): 16; No. of Teeth: 16 — Part ML12205001
Match each specification to its product code
| Cutter Diameter (mm) | Width of Face (mm) | No. of Teeth | Product code (SKU) |
|---|---|---|---|
| 16 | 6.3 | 6 | SEML12201601 |
| 20 | 8 | 6 | SEML12202001 |
| 22 | 9 | 6 | SEML12202201 |
| 25 | 10 | 8 | SEML12202501 |
| 28 | 11 | 8 | SEML12202801 |
| 32 | 12.5 | 10 | SEML12203201 |
| 38 | 16 | 12 | SEML12203801 |
| 40 | 13 | 12 | SEML12204001 |
| 50 | 16 | 16 | SEML12205001 |
