Excision (L12D1) Carbide Miniature Metric Thread Mill
Excision (L12D1) Carbide Miniature Metric Thread Mill. End mills and milling cutters remove material with their cutting end and flutes.
Choosing the right specification
Match cutting diameter, shank, length of cut and reach. Flute count, end shape and coating identify different cutter configurations.
Product details
Product details
- Short thread length
- For Internal Thread
- Thread Depth : 2.0 x D Max.
- Specified features include carbide, TiAlN coating.
Choose by Size and Pitch (mm), then confirm the exact part number for the required cutter.
13 options are available in this product family. Use the selector to choose the required Size and Pitch (mm); each option remains tied to its exact part number.
- Thread form: metric
- Model / series reference: L12D1
Specifications and available options
| Size | M1 M1.2 M1.4 M1.6 M2.2 M2.5 M3 M4 M5 M6 M8 M10 M12 |
|---|---|
| Pitch (mm) | 0.25 0.3 0.35 0.45 0.5 0.7 0.8 1 1.25 1.5 1.75 |
Match each specification to its product code
| Size | Pitch (mm) | Product code (SKU) |
|---|---|---|
| M1 | 0.25 | SEL12D1010 |
| M1.2 | 0.25 | SEL12D1050 |
| M1.4 | 0.3 | SEL12D1070 |
| M1.6 | 0.35 | SEL12D1090 |
| M2.2 | 0.45 | SEL12D1150 |
| M2.5 | 0.45 | SEL12D1170 |
| M3 | 0.5 | SEL12D1200 |
| M4 | 0.7 | SEL12D1240 |
| M5 | 0.8 | SEL12D1280 |
| M6 | 1 | SEL12D1310 |
| M8 | 1.25 | SEL12D1360 |
| M10 | 1.5 | SEL12D1420 |
| M12 | 1.75 | SEL12D1500 |
