Excision HSSco8 (C1132)
Excision HSSco8 (C1132). Countersinks form the recess for a countersunk screw head or prepare the edge of a hole.
Choosing the right specification
Match the included angle and diameter to the fastener head, then choose the cutting form and shank for the setup.
Product details
The YG-1 C1132 is an uncoated HSSCo8 3-flute countersink with a 120° included angle and self-centring geometry. It is designed for deburring, chamfering and countersinking in steel, stainless steel, cast iron and non-ferrous materials.
- Self-centring 3-flute geometry for controlled countersinking and edge finishing.
- HSSCo8 (M42) construction with a bright, uncoated finish.
- Five sizes from 8mm to 25mm outside diameter.
Select the countersink diameter, then confirm the shank diameter and overall length shown for that part number.
- 8mm countersink diameter × 6mm shank × 49mm overall length | 120° — Part C1132080
- 12.5mm countersink diameter × 8mm shank × 54mm overall length | 120° — Part C1132125
- 16mm countersink diameter × 10mm shank × 57mm overall length | 120° — Part C1132160
- 20mm countersink diameter × 10mm shank × 59mm overall length | 120° — Part C1132200
- 25mm countersink diameter × 10mm shank × 65mm overall length | 120° — Part C1132250
Available specifications and product codes
| Specification | Product code (SKU) |
|---|---|
| HSSCo8 120? 3FL. COUNTERSINK Ø8xØ6x49-120? | SEC1132080 |
| HSSCo8 120? 3FL. COUNTERSINK Ø12.5xØ8x54-120? | SEC1132125 |
| HSSCo8 120? 3FL. COUNTERSINK Ø16.0xØ10x57-120? | SEC1132160 |
| HSSCo8 120? 3FL. COUNTERSINK Ø20.0xØ10x59-120? | SEC1132200 |
| HSSCo8 120? 3FL. COUNTERSINK Ø25.0xØ10x65-120? | SEC1132250 |
