Excision (GMF52) V7 Plus Carbide, 4Flute Multi Helix End Mill, Short length, Plain Shank. End mills and milling cutters remove material with their cutting end and flutes.
Choosing the right specification
Match cutting diameter, shank, length of cut and reach. Flute count, end shape and coating identify different cutter configurations.
Product details
Product details
GMF52/GMF56 series CHAMFER EDGE PREP end mills are available from 3-20mm diameter with a plain shank. The V7 plus range from YG-1 offer the highest metal removal rates and silent machining of steels, stainless steels, heat resistant super alloys such as inconel & cast iron. The special multiple helix design eliminates vibration when employing large cuts and high feed rates. The results are tool life, excellent surface finish and the shortest cycle times. For the best results use in a hydraulic chuck or high-performance tool holder with excellent clamping torque.
- Y1200 coated ultrafine micrograin carbide
- HPC (High performance cutting)
- Multiple helix geometries and unequal flute spacing enable higher feed rates and larger cut depths
- Helix & unequal flute spacing reduces vibration
- High heat resistance of Y1200 coating ensures exceptional tool life in stainless steel, titanium and HRSA machining
- Chamfer corner protection to prevent against tool chipping
Specifications
| Flutes | 4 |
| Helix Angle | 35°/37° (Multiple Helix) |
| Cutting Edge Shape | Square |
| Size Min | D3.0 |
| Size Max | D20.0 |
- Specified features include carbide, 4-flute geometry.
- V7 PLUS 4FL MPH SHORT E/M 3X6X7X54 — Part GMF52030
- V7 PLUS 4FL MPH SHORT E/M 4X6X8X54 — Part GMF52040
- V7 PLUS 4FL MPH SHORT E/M 5X6X10X54 — Part GMF52050
- V7 PLUS 4FL MPH SHORT E/M 6X6X10X54 — Part GMF52060
- V7 PLUS 4FL MPH SHORT E/M 8X8X12X58 — Part GMF52080
- V7 PLUS 4FL MPH SHORT E/M 10X10X14X66 — Part GMF52100
- V7 PLUS 4FL MPH SHORT E/M 12X12X16X73 — Part GMF52120
- V7 PLUS 4FL MPH SHORT E/M 14X14X18X75 — Part GMF52140
- V7 PLUS 4FL MPH SHORT E/M 16X16X22X82 — Part GMF52160
- V7 PLUS 4FL MPH SHORT E/M 18X18X24X84 — Part GMF52180
- V7 PLUS 4FL MPH SHORT E/M 20X20X26X92 — Part GMF52200
Match each specification to its product code
| Specification | Product code (SKU) |
|---|---|
| Mill Diameter (mm): 3 | Chamfer (mm): 0.1 | SEGMF52030 |
| Mill Diameter (mm): 4 | Chamfer (mm): 0.15 | SEGMF52040 |
| Mill Diameter (mm): 5 | Chamfer (mm): 0.15 | SEGMF52050 |
| Mill Diameter (mm): 6 | Chamfer (mm): 0.2 | SEGMF52060 |
| Mill Diameter (mm): 8 | Chamfer (mm): 0.2 | SEGMF52080 |
| Mill Diameter (mm): 10 | Chamfer (mm): 0.3 | SEGMF52100 |
| Mill Diameter (mm): 12 | Chamfer (mm): 0.35 | SEGMF52120 |
| Mill Diameter (mm): 14 | Chamfer (mm): 0.4 | SEGMF52140 |
| Mill Diameter (mm): 16 | Chamfer (mm): 0.4 | SEGMF52160 |
| V7 PLUS 4FL MPH SHORT E/M 18X18X24X84 | SEGMF52180 |
| Mill Diameter (mm): 20 | Chamfer (mm): 0.5 | SEGMF52200 |
