Excision (ESD02) CBN, 2Flute Corner Radius End Mill
Excision (ESD02) CBN, 2Flute Corner Radius End Mill. End mills and milling cutters remove material with their cutting end and flutes.
Choosing the right specification
Match cutting diameter, shank, length of cut and reach. Flute count, end shape and coating identify different cutter configurations.
Product details
Product details
- Higher accuracy, better finishes, longer tool life.
- Special geometry improves tool rigidity at high Speed
- Tighter radius tolerance (±0.005mm) assures higher accuracy.
- Specified features include 2-flute geometry, 30° helix, corner-radius profile.
- Model / series reference: ESD02
- Flutes: 2
Specifications and available options
| Specification | Mill Diameter (mm): 0.5 | Corner Radius: R0.05 Mill Diameter (mm): 1 | Corner Radius: R0.05 Mill Diameter (mm): 1 | Corner Radius: R0.10 Mill Diameter (mm): 1.5 | Corner Radius: R0.10 Mill Diameter (mm): 1.5 | Corner Radius: R0.20 Mill Diameter (mm): 2 | Corner Radius: R0.10 Mill Diameter (mm): 2 | Corner Radius: R0.20 CBN 2FL 30deg. Helix Corner Radius E/M 0.5(R0.05)X4X0.3(2)X50 CBN 2FL 30deg. Helix Corner Radius E/M 1(R0.05)X4X0.7(5)X50 CBN 2FL 30deg. Helix Corner Radius E/M 1(R0.1)X4X0.7(3)X50 CBN 2FL 30deg. Helix Corner Radius E/M 1.5(R0.1)X4X1(5)X50 CBN 2FL 30deg. Helix Corner Radius E/M 1.5(R0.2)X4X1(8)X50 CBN 2FL 30deg. Helix Corner Radius E/M 2(R0.1)X4X1.2(6)X50 CBN 2FL 30deg. Helix Corner Radius E/M 2(R0.2)X4X1.2(10)X50 |
|---|
Match each specification to its product code
| Specification | Product code (SKU) |
|---|---|
| Mill Diameter (mm): 0.5 | Corner Radius: R0.05 | SEESD02005053 |
| Mill Diameter (mm): 1 | Corner Radius: R0.05 | SEESD02010053 |
| Mill Diameter (mm): 1 | Corner Radius: R0.10 | SEESD02010105 |
| Mill Diameter (mm): 1.5 | Corner Radius: R0.10 | SEESD02015108 |
| Mill Diameter (mm): 1.5 | Corner Radius: R0.20 | SEESD02015205 |
| Mill Diameter (mm): 2 | Corner Radius: R0.10 | SEESD02020100 |
| Mill Diameter (mm): 2 | Corner Radius: R0.20 | SEESD02020206 |
| CBN 2FL 30deg. Helix Corner Radius E/M 0.5(R0.05)X4X0.3(2)X50 | SEESD02005052 |
| CBN 2FL 30deg. Helix Corner Radius E/M 1(R0.05)X4X0.7(5)X50 | SEESD02010055 |
| CBN 2FL 30deg. Helix Corner Radius E/M 1(R0.1)X4X0.7(3)X50 | SEESD02010103 |
| CBN 2FL 30deg. Helix Corner Radius E/M 1.5(R0.1)X4X1(5)X50 | SEESD02015105 |
| CBN 2FL 30deg. Helix Corner Radius E/M 1.5(R0.2)X4X1(8)X50 | SEESD02015208 |
| CBN 2FL 30deg. Helix Corner Radius E/M 2(R0.1)X4X1.2(6)X50 | SEESD02020106 |
| CBN 2FL 30deg. Helix Corner Radius E/M 2(R0.2)X4X1.2(10)X50 | SEESD02020200 |
