Excision (EL950) HSS-E (M35) Counterbore
Excision (EL950) HSS-E (M35) Counterbore. Counterbores form a recessed seat around an existing hole.
Choosing the right specification
Match the counterbore diameter, pilot arrangement and depth to the required fastener seat.
Product details
Product details
The 3 Flute Counterbores ideal for making counterbore holes (180° capscrew). The YG-1 EL950 series has 3 flutes and comes in a range of different screw sizes and diameters.
Features & Benefits
- Ideal for making counterbore holes (180° capscrew)
- Solid pilot designed for machining as fillister screw caps or ejector caps in moulds.
- HSS-E Substrate.
- Plain shank.
- Specified features include HSS-E (M35), 3-flute geometry.
Choose by part number, dimensions and compatibility and verify fit against the intended equipment or tooling system.
- Material / grade: HSS-E
- Model / series reference: EL950
Specifications and available options
| Specification | Screw Size (mm): M3 | Pilot Diameter (mm): 3.4 | Cutter Diameter (mm): 6 Screw Size (mm): M3.5 | Pilot Diameter (mm): 3.9 | Cutter Diameter (mm): 6.5 Screw Size (mm): M4 | Pilot Diameter (mm): 4.5 | Cutter Diameter (mm): 8 Screw Size (mm): M5 | Pilot Diameter (mm): 5.5 | Cutter Diameter (mm): 10 Screw Size (mm): M6 | Pilot Diameter (mm): 6.6 | Cutter Diameter (mm): 11 Screw Size (mm): M8 | Pilot Diameter (mm): 9 | Cutter Diameter (mm): 15 Screw Size (mm): M10 | Pilot Diameter (mm): 11 | Cutter Diameter (mm): 18 Screw Size (mm): M12 | Pilot Diameter (mm): 14 | Cutter Diameter (mm): 20 HSSCo5(M35) 3FL Counter Bore Pilot 6X5X14X71 HSSCo5(M35) 3FL Counter Bore Pilot 6X5X14X71 (EL950909) HSSCo5(M35) 3FL Counter Bore Pilot 6.5X5X14X71 HSSCo5(M35) 3FL Counter Bore Pilot 6.5X5X14X71 (EL950910) HSSCo5(M35) 3FL Counter Bore Pilot 8X5X14X71 HSSCo5(M35) 3FL Counter Bore Pilot 8X5X14X71 (EL950911) HSSCo5(M35) 3FL Counter Bore Pilot 10X8X18X80 HSSCo5(M35) 3FL Counter Bore Pilot 10X8X18X80 (EL950912) HSSCo5(M35) 3FL Counter Bore Pilot 11X8X18X80 HSSCo5(M35) 3FL Counter Bore Pilot 11X8X18X80 (EL950913) HSSCo5(M35) 3FL Counter Bore Pilot 15X12.5X22X100 HSSCo5(M35) 3FL Counter Bore Pilot 15X12.5X22X100 (EL950914) HSSCo5(M35) 3FL Counter Bore Pilot 18X12.5X22X100 HSSCo5(M35) 3FL Counter Bore Pilot 18X12.5X22X100 (EL950915) HSSCo5(M35) 3FL Counter Bore Pilot 20X12.5X22X100 HSSCo5(M35) 3FL Counter Bore Pilot 20X12.5X22X100 (EL950916) HSSCo5(M35) 3FL Counter Bore Pilot SET 6,8,10,11,15,18 |
|---|
