Excision (EIA13) D-Power Carbide 3Flute Corner Radius End Mill, Short Length for Graphite (Diamond Coated). End mills and milling cutters remove material with their cutting end and flutes.
Choosing the right specification
Match cutting diameter, shank, length of cut and reach. Flute count, end shape and coating identify different cutter configurations.
Product details
Product details
The YG-1 EIA13 series D-Power diamond coated micrograin carbide cutters have 3 flutes and a plain shank. These end mills have a 40° helix and corner radius for increased wear resistance. These range in diameter from 2mm-12mm. The D-Power range is the first choice for the high-performance machining of graphite. It is also suitable for machining abrasive aluminium, plastics, brass, copper, CFRP and GFRP composites.
- First choice for high performance machining of graphite with extreme wear resistance.
- Excellent performance in abrasive non-ferrous materials.
- Diamond coating has high lubricity and low coefficient of friction, preventing the tool from fast wear common in abrasive material machining.
- Suitable for high accuracy machining.
- Smooth and excellent surface finish on graphite.
- Also suitable for high speed machining of Wrought Aluminium, Bakelite, Plastics, Wood, Brass and non-ferrous metals.
Specifications
| Flutes | 3 |
| Helix Angle | 40° |
| Cutting Edge Shape | CORNER RADIUS |
| Size Min | D2.0 |
| Size Max | D12.0 |
| Length | SHORT LENGTH |
| Coating | Diamond |
- Specified features include carbide, 3-flute geometry, 40° helix, corner-radius profile.
Choose by Mill Diameter (mm) and Corner Radius (mm), then confirm the exact part number for the required cutter.
- Mill Diameter (mm): 2; Corner Radius (mm): R0.15 — Part EIA13020
- Mill Diameter (mm): 3; Corner Radius (mm): R0.15 — Part EIA13030
- Mill Diameter (mm): 4; Corner Radius (mm): R0.2 — Part EIA13040
- Mill Diameter (mm): 5; Corner Radius (mm): R0.3 — Part EIA13050
- Mill Diameter (mm): 6; Corner Radius (mm): R0.3 — Part EIA13060
- Mill Diameter (mm): 8; Corner Radius (mm): R0.5 — Part EIA13080
- Mill Diameter (mm): 10; Corner Radius (mm): R0.5 — Part EIA13100
- Mill Diameter (mm): 12; Corner Radius (mm): R0.5 — Part EIA13120
Match each specification to its product code
| Mill Diameter (mm) | Corner Radius (mm) | Product code (SKU) |
|---|---|---|
| 2 | R0.15 | SEEIA13020 |
| 3 | R0.15 | SEEIA13030 |
| 4 | R0.2 | SEEIA13040 |
| 5 | R0.3 | SEEIA13050 |
| 6 | R0.3 | SEEIA13060 |
| 8 | R0.5 | SEEIA13080 |
| 10 | R0.5 | SEEIA13100 |
| 12 | R0.5 | SEEIA13120 |
