Excision (EI880) D-Power Carbide 2Flute Ball Nose End Mill, Short Length Neck for Graphite (Diamond Coated)

(EI880) D-Power Carbide 2-flute Ball Nose End Mill, Short Length Neck for Graphite (Diamond Coated) is an carbide, 2-flute geometry, 30° helix end mill for profiling, contoured surfaces and radius-bottom features. The range keeps the cutter geometry and size information close to each selectable option.

Product details

The YG-1 EI880 series D-Power diamond coated micrograin carbide cutters has 2 flutes and a plain shank. These short length end mills have a reduced neck and a ball nosed end for machining radii. These range in diameter from 6mm-12mm. The D-Power range is the first choice for the high performance machining of graphite. It is also suitable for machining abrasive aluminium, plastics, brass, copper, CFRP and GFRP composites.

• First choice for high performance machining of graphite with extreme wear resistance.
• Excellent performance in abrasive non-ferrous materials.
• Diamond coating has high lubricity and low coefficient of friction, preventing the tool from fast wear common in abrasive material machining.
• Ball nosed gemoetry.
• Reduced neck for deep pocket machining.
• Suitable for high accuracy machining.
• Smooth and excellent surface finish on graphite.
• Also suitable for high speed machining of Wrought Aluminium, Bakelite, Plastics, Wood, Brass and non-ferrous metals.

Specifications

Why choose it

• Specified features include carbide, 2-flute geometry, 30° helix, ball-nose profile.
• Dimensions and geometry are presented together to make tool selection faster.
• Available in 10 options so the required size or configuration can be selected without changing product family.

Choose the right option

Choose by Mill Diameter (mm) and Ball Nose Radius (mm), then confirm the exact part number for the required cutter.

• Mill Diameter (mm): 2; Ball Nose Radius (mm): R1.0 — Part EI880020
• Mill Diameter (mm): 2.5; Ball Nose Radius (mm): R1.25 — Part EI880025
• Mill Diameter (mm): 3; Ball Nose Radius (mm): R1.5 — Part EI880030
• Mill Diameter (mm): 3.5; Ball Nose Radius (mm): R1.75 — Part EI880035
• Mill Diameter (mm): 4; Ball Nose Radius (mm): R2.0 — Part EI880040
• Mill Diameter (mm): 5; Ball Nose Radius (mm): R2.5 — Part EI880050
• Mill Diameter (mm): 6; Ball Nose Radius (mm): R3.0 — Part EI880060
• Mill Diameter (mm): 8; Ball Nose Radius (mm): R4.0 — Part EI880080
• Mill Diameter (mm): 10; Ball Nose Radius (mm): R5.0 — Part EI880100
• Mill Diameter (mm): 12; Ball Nose Radius (mm): R6.0 — Part EI880120
