Excision (DT692) HSS-E (M35) Extra Long series Drill for Deep Hole ...
Excision (DT692) HSS-E (M35) Extra Long series Drill for Deep Hole (TiAlN Coated) Worm Pattern. Drill bits produce holes using the cutting geometry and shank specified for the tool.
Choosing the right specification
Choose diameter, flute length and shank for the required hole and drill. Material and coating are specific to the selected item.
Product details
(DT692) HSS-E (M35) Extra Long series Drill for Deep Hole (TiAlN Coated) Worm Pattern is an HSS-E (M35), TiAlN coating, straight shank drill range for producing holes to the selected diameter and length specification. Each option keeps the cutting dimensions with its exact part number.
Product details
Features & Benefits
- 20xD Extra Long Length Drill for Deep Hole Drilling.
- Made from a HSS substrate with a 5% cobalt content.
- Bright Finish.
- Suitable for machining Non Alloy Steels, Alloy Steels, Grey Cast Iron, Malleable Cast Iron, Special Aluminum or Magnesium Alloys.
- Worm pattern drills feature a parabolic u-shaped flute for efficient chip evacuation.
- Bright finish prevents built up edge and deep flute pockets prevent chip clogging.
- Excellent for soft or long chipping materials.
- Specified features include HSS-E (M35), TiAlN coating, straight shank, extra-long length.
- Diameter and length data support accurate tool selection.
Choose by drill diameter, flute length and overall length and confirm the shank fits the intended holder or machine.
- Material / grade: HSS-E
- Model / series reference: DT692
Specifications and available options
| Specification | Drill Diameter (mm): 3 Drill Diameter (mm): 3.5 Drill Diameter (mm): 4 Drill Diameter (mm): 5.5 Drill Diameter (mm): 6 Drill Diameter (mm): 6.5 Drill Diameter (mm): 7 Drill Diameter (mm): 7.5 Drill Diameter (mm): 8 Drill Diameter (mm): 8.5 Drill Diameter (mm): 9 Drill Diameter (mm): 9.5 Drill Diameter (mm): 10 Drill Diameter (mm): 10.2 HSSCo5(M35) Ex-Long DH100 Type Straight Shank Drill(TiAlN) 4.5X160X235 HSSCo5(M35) Ex-Long DH100 Type Straight Shank Drill(TiAlN) 5X170X245 |
|---|
Match each specification to its product code
| Specification | Product code (SKU) |
|---|---|
| Drill Diameter (mm): 3 | SEDT692030 |
| Drill Diameter (mm): 3.5 | SEDT692035 |
| Drill Diameter (mm): 4 | SEDT692040 |
| Drill Diameter (mm): 5.5 | SEDT692055 |
| Drill Diameter (mm): 6 | SEDT692060 |
| Drill Diameter (mm): 6.5 | SEDT692065 |
| Drill Diameter (mm): 7 | SEDT692070 |
| Drill Diameter (mm): 7.5 | SEDT692075 |
| Drill Diameter (mm): 8 | SEDT692080 |
| Drill Diameter (mm): 8.5 | SEDT692085 |
| Drill Diameter (mm): 9 | SEDT692090 |
| Drill Diameter (mm): 9.5 | SEDT692095 |
| Drill Diameter (mm): 10 | SEDT692100 |
| Drill Diameter (mm): 10.2 | SEDT692102 |
| HSSCo5(M35) Ex-Long DH100 Type Straight Shank Drill(TiAlN) 4.5X160X235 | SEDT692045 |
| HSSCo5(M35) Ex-Long DH100 Type Straight Shank Drill(TiAlN) 5X170X245 | SEDT692050 |
