Excision DIN371/DIN376 Straight Flute TiCN (T0999-TIC)
DIN371/DIN376 Straight Flute TiCN (T0999-TIC) is an carbide, TiCN coating, straight flutes tap range for cutting internal threads. Thread size, pitch, geometry and length remain tied to the selected option.
Product details
- Carbide tap can increase tool life longer than HSS taps due to higher hardness.
Suitable for hardened steels (HRc50~60)
Why choose it
- Specified features include carbide, TiCN coating, straight flutes, DIN371.
- Thread and geometry details are grouped for faster application matching.
- Available in 11 options so the required size or configuration can be selected without changing product family.
Choose the right option
Choose by Size and Pitch (mm), then confirm work material and hole type against current cutting data.
- Size: M3; Pitch (mm): 0.5 — Part T0999206TIC
- Size: M4; Pitch (mm): 0.7 — Part T0999246TIC
- Size: M5; Pitch (mm): 0.8 — Part T0999286TIC
- Size: M6; Pitch (mm): 1 — Part T0999316TIC
- Size: M8; Pitch (mm): 1.25 — Part T0999366TIC
- Size: M10; Pitch (mm): 1.5 — Part T0999426TIC
- Size: M12; Pitch (mm): 1.75 — Part T0999506TIC
- Size: M14; Pitch (mm): 2 — Part T0999546TIC
- Size: M16; Pitch (mm): 2 — Part T0999606TIC
- Size: M18; Pitch (mm): 2.5 — Part T0999656TIC
- Size: M20; Pitch (mm): 2.5 — Part T0999706TIC
