Excision (DH424) Dream Drill 5XD without Coolant Hole - 1 to 5.6
(DH424) Dream Drill 5XD without Coolant Hole - 1 to 5.6 is an TiAlN coating, DIN 6537 drill range for producing holes to the selected diameter and length specification. Each option keeps the cutting dimensions with its exact part number.
Product details
The YG-1 DH424 General Carbide Dream Drills are a stub length drill designed for high performance drilling of Steel up to HRc45 and Cast Iron. These self centering drills can drill to a h7 tolerance which eliminates any reaming operations. Diameters range from 1-20mm and they are supplied with parallel shanks.
- Micrograin Carbide Substrate
- TiAlN Coated High Performance Drill
- 5xD Stub Length
- Self Centering with 140 degree Drill Point
- High Performance Drilling on Steel
- Eliminates Reaming Operations
- Also Suitable for Stainless Steel Drilling
Specifications
| Drilling Depth | 5XD |
| Length | LONG |
| Size Min | D1.0 |
| Size Max | D20.0 |
| Coating | TiAIN |
Why choose it
- Specified features include TiAlN coating, DIN 6537.
- Diameter and length data support accurate tool selection.
- Available in 50 options so the required size or configuration can be selected without changing product family.
Choose the right option
Choose by drill diameter, flute length and overall length and confirm the shank fits the intended holder or machine.
50 options are available in this product family. Use the selector to choose the required drill diameter, flute length and overall length; each option remains tied to its exact part number.
