Excision (D2320) HSSCo8% (M42) NC Spotting Drill 142°
Excision (D2320) HSSCo8% (M42) NC Spotting Drill 142°. Drill bits produce holes using the cutting geometry and shank specified for the tool.
Choosing the right specification
Choose diameter, flute length and shank for the required hole and drill. Material and coating are specific to the selected item.
Product details
(D2320) HSSCo8% (M42) NC Spotting Drill 142° is an HSSCo8 (M42) drill range for producing holes to the selected diameter and length specification. Each option keeps the cutting dimensions with its exact part number.
Product details
Application : For more precise centering work on NC/CNC Machines.The large diameter of the tool permits chamfering work after centering continuously.
- Specified features include HSSCo8 (M42).
- Diameter and length data support accurate tool selection.
Choose by drill diameter, flute length and overall length and confirm the shank fits the intended holder or machine.
- HSSCo8(M42) NC Spotting Drill(142deg.) 3X12X46 — Part D2320030
- HSSCo8(M42) NC Spotting Drill(142deg.) 4X12X55 — Part D2320040
- HSSCo8(M42) NC Spotting Drill(142deg.) 5X15X60 — Part D2320050
- HSSCo8(M42) NC Spotting Drill(142deg.) 6X20X66 — Part D2320060
- HSSCo8(M42) NC Spotting Drill(142deg.) 8X25X79 — Part D2320080
- HSSCo8(M42) NC Spotting Drill(142deg.) 10X25X89 — Part D2320100
- HSSCo8(M42) NC Spotting Drill(142deg.) 12X30X102 — Part D2320120
- HSSCo8(M42) NC Spotting Drill(142deg.) 16X35X115 — Part D2320160
- HSSCo8(M42) NC Spotting Drill(142deg.) 20X40X131 — Part D2320200
- HSSCo8(M42) NC Spotting Drill(142deg.) 25X45X138 — Part D2320250
- Model / series reference: D2320
- Stated angle: 142°
Specifications and options
| Specification | Drill Diameter (mm): 3 Drill Diameter (mm): 4 Drill Diameter (mm): 5 Drill Diameter (mm): 6 Drill Diameter (mm): 8 Drill Diameter (mm): 10 Drill Diameter (mm): 12 Drill Diameter (mm): 16 Drill Diameter (mm): 20 HSSCo8(M42) NC Spotting Drill(142deg.) 25X45X138 |
|---|
Match each specification to its product code
| Specification | Product code (SKU) |
|---|---|
| Drill Diameter (mm): 3 | SED2320030 |
| Drill Diameter (mm): 4 | SED2320040 |
| Drill Diameter (mm): 5 | SED2320050 |
| Drill Diameter (mm): 6 | SED2320060 |
| Drill Diameter (mm): 8 | SED2320080 |
| Drill Diameter (mm): 10 | SED2320100 |
| Drill Diameter (mm): 12 | SED2320120 |
| Drill Diameter (mm): 16 | SED2320160 |
| Drill Diameter (mm): 20 | SED2320200 |
| HSSCo8(M42) NC Spotting Drill(142deg.) 25X45X138 | SED2320250 |
