Excision (D2107) HSSCo8% (M42) Stub Drill for Multi Purpose (Gold Coloring) - M42

(D2107) HSSCo8% (M42) Stub Drill for Multi Purpose (Gold Coloring) - M42 is an HSSCo8 (M42), straight shank, DIN 1897 drill range for producing holes to the selected diameter and length specification. Each option keeps the cutting dimensions with its exact part number.

Product details

The D2107 series are an uncoated style stub length drill made from HSS 8 Percent Cobalt for increased tool life compared to standard HSS drills. Ideal for low hardness steels, cast iron and aluminium. Diameters range from 1-30mm.

• 3xD Stub Drill.
• Made from a HSS substrate with an 8% cobalt substrate.
• Bright finish for aluminium drilling.
• Suitable for machining Steel
• Great tool life and performance compared to HSS drills due to 8% Cobalt content.
• Ideal for low hardness steels, cast iron & aluminium.
• Also suitable for stainless steel, inconel and titanium.
• Normal point up to 1.6mm, split point over 1.6mm for higher accuracy drilling.

Specifications

Why choose it

• Specified features include HSSCo8 (M42), straight shank, DIN 1897.
• Diameter and length data support accurate tool selection.
• Available in 29 options so the required size or configuration can be selected without changing product family.

Choose the right option

Choose by drill diameter, flute length and overall length and confirm the shank fits the intended holder or machine.

29 options are available in this product family. Use the selector to choose the required drill diameter, flute length and overall length; each option remains tied to its exact part number.
