Excision (D1363) HSS Centre Drill / Form R
Excision (D1363) HSS Centre Drill / Form R. Drill bits produce holes using the cutting geometry and shank specified for the tool.
Choosing the right specification
Choose diameter, flute length and shank for the required hole and drill. Material and coating are specific to the selected item.
Product details
(D1363) HSS Centre Drill / Form R is an HSS, DIN333 drill range for producing holes to the selected diameter and length specification. Each option keeps the cutting dimensions with its exact part number.
Product details
YG-1 D1363 HSS centre drills are Form R, metric 60° tools with radius. A long pilot improves alignment and stability when starting accurate centre holes. Uncoated bright finish and plain shank suit general-purpose machining across steel, stainless steel, and non-ferrous. Made from a high quality HSS substrate, they provide reliable performance for low cost centring.
- Specified features include HSS, DIN333.
- Diameter and length data support accurate tool selection.
Choose by drill diameter, flute length and overall length and confirm the shank fits the intended holder or machine.
- HSS(M2) Center Drill Form R DIN333 .5X3.15XR1.25X25 — Part D1363005
- HSS(M2) Center Drill Form R DIN333 .8X3.15XR2X25 — Part D1363008
- HSS(M2) Center Drill Form R DIN333 1X3.15XR2.5X31.5 — Part D1363010
- HSS(M2) Center Drill Form R DIN333 1.25X3.15XR3.15X31.5 — Part D1363912
- HSS(M2) Center Drill Form R DIN333 1.6X4XR4X35.5 — Part D1363016
- HSS(M2) Center Drill Form R DIN333 2.5X6.3XR6.3X45 — Part D1363025
- HSS(M2) Center Drill Form R DIN333 3.15X8XR8X50 — Part D1363931
- HSS(M2) Center Drill Form R DIN333 4X10XR10X56 — Part D1363040
- HSS(M2) Center Drill Form R DIN333 5X12.5XR12.5X63 — Part D1363050
- HSS(M2) Center Drill Form R DIN333 6.3X16XR16X71 — Part D1363063
- HSS(M2) Center Drill Form R DIN333 8X20XR20X80 — Part D1363080
- HSS(M2) Center Drill Form R DIN333 2X5XR5X40 — Part D1363020
- Material / grade: HSS
- Model / series reference: D1363
Specifications and options
| Specification | Drill Diameter (mm): 0.5 Drill Diameter (mm): 0.8 Drill Diameter (mm): 1.0 Drill Diameter (mm): 1.25 Drill Diameter (mm): 1.6 Drill Diameter (mm): 2.5 Drill Diameter (mm): 3.15 Drill Diameter (mm): 4.0 Drill Diameter (mm): 5.0 Drill Diameter (mm): 6.3 Drill Diameter (mm): 8.0 HSS(M2) Center Drill Form R DIN333 2X5XR5X40 |
|---|
Match each specification to its product code
| Specification | Product code (SKU) |
|---|---|
| Drill Diameter (mm): 0.5 | SED1363005 |
| Drill Diameter (mm): 0.8 | SED1363008 |
| Drill Diameter (mm): 1.0 | SED1363010 |
| Drill Diameter (mm): 1.25 | SED1363912 |
| Drill Diameter (mm): 1.6 | SED1363016 |
| Drill Diameter (mm): 2.5 | SED1363025 |
| Drill Diameter (mm): 3.15 | SED1363931 |
| Drill Diameter (mm): 4.0 | SED1363040 |
| Drill Diameter (mm): 5.0 | SED1363050 |
| Drill Diameter (mm): 6.3 | SED1363063 |
| Drill Diameter (mm): 8.0 | SED1363080 |
| HSS(M2) Center Drill Form R DIN333 2X5XR5X40 | SED1363020 |
