Excision (C1139) HSSCo8% (M42) 3Flute Countersink 90°
Excision (C1139) HSSCo8% (M42) 3Flute Countersink 90°. Countersinks form the recess for a countersunk screw head or prepare the edge of a hole.
Choosing the right specification
Match the included angle and diameter to the fastener head, then choose the cutting form and shank for the setup.
Product details
(C1139) HSSCo8% (M42) 3-flute Countersink 90° is an HSSCo8 (M42), 3-flute geometry countersink for deburring, chamfering and producing countersunk seats to the selected geometry.
Product details
The YG-1 C1139 series 3 flute, uncoated, 90 degree countersink are for general machining of steel, stainless steel, cast iron and non-ferrous materials. These have a self centering geometry for deburring, chamfering and countersinking.
- Specified features include HSSCo8 (M42), 3-flute geometry.
- Angle and diameter data support accurate countersink selection.
Choose by countersink diameter, angle, shank and overall length.
- Model / series reference: C1139
- Flutes: 3
- Stated angle: 90°
Specifications and available options
| Specification | Cutter Diameter (mm): 4.3 Cutter Diameter (mm): 5 Cutter Diameter (mm): 6 Cutter Diameter (mm): 6.3 Cutter Diameter (mm): 7 Cutter Diameter (mm): 8 Cutter Diameter (mm): 8.3 Cutter Diameter (mm): 10 Cutter Diameter (mm): 10.4 Cutter Diameter (mm): 11.5 Cutter Diameter (mm): 12.4 Cutter Diameter (mm): 15 HSSCo8 90? 3FL. COUNTERSINK Ø35xØ16x110-90? HSSCo8 90? 3FL. COUNTERSINK Ø40xØ16x115-90? HSSCo8 90? 3FL. COUNTERSINK Ø45xØ16x120-90? HSSCo8 90? 3FL. COUNTERSINK Ø50xØ16x130-90? Cutter Diameter (mm): 16.5 Cutter Diameter (mm): 19 Cutter Diameter (mm): 20.5 Cutter Diameter (mm): 23 Cutter Diameter (mm): 25 Cutter Diameter (mm): 30 Cutter Diameter (mm): 31 HSSCo8 90? 3FL. COUNTERSINK SET6 6.3,8.3,10.4,12.4,16.5,20.5 |
|---|
Match each specification to its product code
| Specification | Product code (SKU) |
|---|---|
| Cutter Diameter (mm): 4.3 | SEC1139043 |
| Cutter Diameter (mm): 5 | SEC1139050 |
| Cutter Diameter (mm): 6 | SEC1139060 |
| Cutter Diameter (mm): 6.3 | SEC1139063 |
| Cutter Diameter (mm): 7 | SEC1139070 |
| Cutter Diameter (mm): 8 | SEC1139080 |
| Cutter Diameter (mm): 8.3 | SEC1139083 |
| Cutter Diameter (mm): 10 | SEC1139100 |
| Cutter Diameter (mm): 10.4 | SEC1139104 |
| Cutter Diameter (mm): 11.5 | SEC1139115 |
| Cutter Diameter (mm): 12.4 | SEC1139124 |
| Cutter Diameter (mm): 15 | SEC1139150 |
| HSSCo8 90? 3FL. COUNTERSINK Ø35xØ16x110-90? | SEC1139350 |
| HSSCo8 90? 3FL. COUNTERSINK Ø40xØ16x115-90? | SEC1139400 |
| HSSCo8 90? 3FL. COUNTERSINK Ø45xØ16x120-90? | SEC1139450 |
| HSSCo8 90? 3FL. COUNTERSINK Ø50xØ16x130-90? | SEC1139500 |
| Cutter Diameter (mm): 16.5 | SEC1139165 |
| Cutter Diameter (mm): 19 | SEC1139190 |
| Cutter Diameter (mm): 20.5 | SEC1139205 |
| Cutter Diameter (mm): 23 | SEC1139230 |
| Cutter Diameter (mm): 25 | SEC1139250 |
| Cutter Diameter (mm): 30 | SEC1139300 |
| Cutter Diameter (mm): 31 | SEC1139310 |
| HSSCo8 90? 3FL. COUNTERSINK SET6 6.3,8.3,10.4,12.4,16.5,20.5 | SEC1139S60 |
