Excision (C1136) HSSCo8% (M42) 3Flute Countersink 60°
Excision (C1136) HSSCo8% (M42) 3Flute Countersink 60°. Countersinks form the recess for a countersunk screw head or prepare the edge of a hole.
Choosing the right specification
Match the included angle and diameter to the fastener head, then choose the cutting form and shank for the setup.
Product details
(C1136) HSSCo8% (M42) 3-flute Countersink 60° is an HSSCo8 (M42), 3-flute geometry countersink for deburring, chamfering and producing countersunk seats to the selected geometry.
Product details
The YG-1 C1136 series 3 flute, uncoated, 60 degree countersink are for general machining of steel, stainless steel, cast iron and non-ferrous materials. These have a self centering geometry for deburring, chamfering and countersinking.
- Specified features include HSSCo8 (M42), 3-flute geometry.
- Angle and diameter data support accurate countersink selection.
Choose by Cutter Diameter (mm).
- Cutter Diameter (mm): 6.3 — Part C1136063
- Cutter Diameter (mm): 8 — Part C1136080
- Cutter Diameter (mm): 10 — Part C1136100
- Cutter Diameter (mm): 12.5 — Part C1136125
- Cutter Diameter (mm): 16 — Part C1136160
- Cutter Diameter (mm): 20 — Part C1136200
- Cutter Diameter (mm): 25 — Part C1136250
- Model / series reference: C1136
- Flutes: 3
- Stated angle: 60°
Specifications and options
| Cutter Diameter (mm) | 6.3 8 10 12.5 16 20 25 |
|---|
Match each specification to its product code
| Cutter Diameter (mm) | Product code (SKU) |
|---|---|
| 6.3 | SEC1136063 |
| 8 | SEC1136080 |
| 10 | SEC1136100 |
| 12.5 | SEC1136125 |
| 16 | SEC1136160 |
| 20 | SEC1136200 |
| 25 | SEC1136250 |
